Gates

Recommended For: High pressure hydraulic oil lines. Meets or exceeds the requirements of SAE 100R2AT and performance requirements of EN 853. Meets flame resistance acceptance designation MSHA 2G

Tube: Black oil resistant, synthetic rubber (Nitrile-Type C).

Reinforcement: Two braids, of high-tensile steel wire.

Cover: Black, oil resistant, synthetic rubber. (Hypalon® - Type M).

Temperature Range: -40° F to +275°F (-40° C to + 135°C) constant and +300° F (+149°C) intermittent - up to 10% of operating time.

Couplings: Super-Crimp series

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Non-severe, high pressure hydraulics applications with low flexure requirements.

Tube: Black, oil resistant, synthetic rubber (Nitrile).

Reinforcement: Two braids of high-tensile steel wire.

Cover: Black, abrasion-resistant synthetic rubber (Modified SBR).

Temperature Range: -40°F to +212°F (-40°C to +100°C)

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Hydraulic jack applications. Meets Material Handling Institute specification IJ 100 for hydraulic hose and assemblies used with jacking systems. Meets flame resistance acceptance designation MSHA 2G

Tube: Black oil resistant, synthetic rubber (Nitrile-Type C).

Reinforcement: Two braids, of high-tensile steel wire.

Cover: Black, oil and abrasion resistant thin synthetic rubber (Modified Nitrile - Type C ).

Temperature Range: -40° F to +120° F (-40° C to +49°C).

Couplings: Super-Crimp and Ezi-Crimp series.

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Medium pressure hydraulic lines. Meets or exceeds the requirements of SAE 100R1 Type AT and SAE 100R1 Type S and performance requirements of EN 853 2SN. Meets flame resistance acceptance designation MSHA 2G

Tube: Black oil resistant, synthetic rubber (Nitrile-Type C).

Reinforcement: One braid of high-tensile steel wire.

Cover: Black, oil and abrasion-resistant, synthetic rubber (Modified Nitrile - Type C₂).

Temperature Range: -40°F to +212°F (-40°C to +100°C).

Couplings: Super-Crimp, Ezi-Crimp and Gates Mega Crimp series

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Medium pressure hydraulic oil lines. Meets or exceeds the requirements fossae 100R1 Type AT.

Tube: Black oil resistant, synthetic rubber (Nitrile-Type C).

Reinforcement: One braid of high-tensile steel wire.

Cover: Black, oil and abrasion-resistant, synthetic rubber (Modified Nitrile - Type C₂ ).

Temperature Range: -40°F to +275°F (-40°C to +135°C).

Couplings: Super-Crimp, Ezi-Crimp and Gates Mega Crimp series

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Non-severe, medium pressure hydraulics applications with low flexure requirements.

Tube: Black, oil resistant, synthetic rubber (Nitrile).

Reinforcement: One braid of high-tensile steel wire.

Cover: Black, abrasion-resistant synthetic rubber (Modified SBR).

Temperature Range: -40°F to +212°F (-40°C to +100°C)

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Multipurpose medium-pressure, high-temperature, air compressor lines, petroleum-base or phosphate ester hydraulic fluid supplies. Meets or exceeds the requirements of SAE 100R2AT and SAE100R2 Type S.

Tube: Black, oil-resistant, synthetic rubber (CPE - Type J).

Reinforcement: Two braids of high tensile steel wire.

Cover: Blue, oil and abrasion-resistant polyester braid.

Temperature Range: -40°F to +300°F (-40°C to +149°C).

Couplings: Super-Crimp and Gates Mega-Crimp series.

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Air brake, pressurised hot oil return lines and rotary oil/air compressor lines, Meets the requirements of DOT FMVSS 106-74, SAE J1402, SAE J1019 performance specifications for high-temperature transmission and lubrication oil systems using petroleum-based oils.

Tube: True-bore GTS black tube, specifically compounded for temperature and chemical resistance (CPE - Type J)*

Reinforcement: One braid of high-tensile steel wire.

Cover: Oil and mildew resistant textile braid, impregnated with synthetic rubber.

Temperature Range: Petroleum-base fluids -40°F to +300°F (-40°C to +149°C). Phosphate ester fluids as recommended by the fluid manufacturer, but within a range of -40°F to +212°F (-40°C to +100°C).

Couplings: Super-Crimp and Gates Mega-Crimp series.

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended for: Low pressure powder fire suppressant applications in mining, forestry and fire fighting equipment. The red cover is for easy visual identification in these applications.

Standards: Meets performance requirements of SAE 100R1

Tube: Black, oil resistant, synthetic rubber (Nitrile)

Reinforcement: One braid of high-tensile steel wire

Cover: Red, oil- and abrasion-resistant synthetic rubber (Modified Nitrile)

Temperature Range: -40°F to +212°F (-40°C to +100°C)

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Air brake, pressurised hot oil return lines and rotary oil/air compressor lines, Meets the requirements of DOT SAE J1019 performance specifications for high-temperature transmission and lubricating oil systems using petroleum base oils. Not recommended for petrol or diesel applications.

Tube: GTS black tube, specifically compounded for temperature and chemical resistance (CPE - Type J)

Reinforcement: One braid of high-tensile steel wire.

Cover: Oil and mildew resistant textile braid, impregnated with synthetic rubber.

Temperature Range: Petroleum-base fluids -40°F to +300°F (-40°C to +149°C). Phosphate ester fluids recommended by the fluid manufacturer, but within range of -40°F 70 + 212°F (-40°C to + 100°C).

Couplings: Gates GL Series.

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Medium pressure hydraulic petroleum-based oil lines in impulse applications, lube oil, air and water in applications such as air brakes, power steering (CAUTION: Intended for heavy-duty commercial vehicle use only), Turbocharger oil supplies, tilt cab cylinders, transmission coolant and filtration lines. Meets or exceeds requirements of SAE 100R5 for traditional hydraulic applications. DOT FMVSS 106-74 Type - All and SAE J1402 Type All for air brake applications (-4 and -12). Not recommended for gasoline or diesel fuel.

Tube: -4 and -5: black, oil and heat resistant synthetic rubber (Neoprene Type A). -6 thru -40 (Nitrile - Type C).

Reinforcement: One braid of high tensile carbon steel wire over one braid of polyester.

Cover: Black, oil and mildew resistant, polyester braid.

Temperature Range: Under SAE 100R5 (hydraulic) conditions -40°F to +212°F (-40°C to +100°C). All-purpose fleet application (hot lube oil lines) -40°F to +300°F (-40°C to +149°C). Air to +160°F (+71°C) only. For water emulsions etc. Avoid continuous use at maximum temperature concurrent with maximum working pressure.

Couplings: Super-Crimp and C5 Field-Fit series.

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Extremely high temperature petroleum based or phosphate ester fluids, turbo charger oil supply and hot lube oil lines.

Standards: Meets the requirememts of SAEJ1405 performance specifications for high temperature transmission and lubrication oil systems.

Tube: Black, oiland heat-resistant synthetic polymer tube (PE-Type J)

Reinforcement: Braided high-tensile wire and textile.

Cover: Blue, oil and mildew resistant polyester/textile braid.

Temperature Range: -40°F to +302°F (-40°C to +150°C)

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Air brake hose, power steering (CAUTION: Intended for heavy-duty commercial vehicle use only), fuel filter, engine and transmission coolant lines, and hot (+300°F) lube oil lines.

Tube: Black, oil and heat resistant, synthetic rubber. (Nitrile - Type C).

Reinforcement: One braid of high-tensile steel wire over one braid of polyester.

Cover: Black, oil and heat resistant, textile braid impregnated with synthetic rubber. Green stripe for easy identification.

Temperature Range: -40°F to +300°F (-40°C to +149°C). Air to +250°F (+121°C) maximum only.

Couplings: Super-Crimp and Field-Fit C5E series.

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Hydraulic oil lines, anti-freeze solutions or water. Meets or exceeds requirements of SAE 100R3.

Tube: Black, synthetic rubber (Nitrile - Type C).

Reinforcement: Two fibre braids.

Cover: Black oil and abrasion resistant, synthetic rubber (Neoprene - Type A).

Temperature Range: For Hydraulic oil lines -40°F to 275°F (-40°C to +135°C) constant and +300°F (+149°C) intermittent (up to 10% of operating time).

Couplings: Super-Crimp series.

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Use with petroleum, water base and synthetic hydraulic fluids. Applications include: power and telephone mobile equipment (cherry pickers), lubrication lines, blowout preventer control lines, hydraulic lifts and farm and construction equipment. TH8 hoses meet or exceed performance requirements of SAE 100R8 with significantly tighter bend radius. Multiline available.

Tube: 100% seamless Nylon Type Z. Easily handles a broad range of hydraulic fluids, including phosphate esters and water glycol.

Reinforcement: Two polyester braids.

Cover: Black urethane resists hydraulic fluids, high temperatures, aging and weather. Black cover is perforated for use in general hydraulic and pneumatic service.

Temperature Range: -65°F to +200°F (-54°C to +93°C) continuous service for petroleum and synthetic oils. Maximum of 158°F (+70°C) for water, water/oil emulsions and water glycol.

Couplings: Gates Mega-Crimp series.

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Use with petroleum, water base and synthetic hydraulic fluids. Applications include: power and telephone mobile equipment (cherry pickers), lubrication lines, blowout preventer control lines, hydraulic lifts and farm and construction equipment. TH8 hoses meet or exceed performance requirements of SAE 100R8 with significantly tighter bend radius. Multiline available. Tube: 100% seamless Nylon Type Z. Easily handles a broad range of hydraulic fluids, including phosphate esters and water glycol.

Reinforcement: Two polyester braids.

Cover: Orange urethane resists hydraulic fluids, high temperatures, aging and weather. Orange cover is non-perforated for applications requiring electrical non-conductivity. Meets SAE 100R8 Electrical Conductivity test.

Temperature Range: -65°F to +200°F (-54°C to +93°C) continuous service for petroleum and synthetic oils. Maximum of 158°F (+70°C) for water, water/oil emulsions and water glycol.

Couplings: Gates Mega-Crimp series.

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Petroleum, water base and synthetic hydraulic fluids. Applications include: power and telephone mobile equipment (cherry pickers), lubrication lines, blowout preventer control lines, hydraulic lifts and farm and construction machinery. TH7 hoses meet or exceed performance requirements of SAE 100R7 with significantly tighter bend radius.

Tube: 100% seamless Nylon Type Z. Easily handles a broad range of hydraulic fluids, including phosphate esters and water glycol.

Reinforcement: Synthetic Fibre.

Cover: Black polyurethane that resists hydraulic fluids, high temperatures, aging and weathering. Black TH7 is perforated for use in general hydraulic and pneumatic service.

Temperature Range: -65°F to +200°F (-54°C to +93°C) continuous service for petroleum and synthetic oils. Maximum of 158°F (+70°C) for water, water/oil emulsions and water glycol.

Couplings: Super-Crimp series and Gates Mega-Crimp series.

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Petroleum, water base and synthetic hydraulic fluids. Applications include: power and telephone mobile equipment (cherry pickers), lubrication lines, blowout preventer control lines, hydraulic lifts and farm and construction machinery. Orange colour TH7NC meets SAE 100R7 non-conductivity requirements. TH7NC hose meets or exceed performance requirements of SAE 100R7 with significantly tighter bend radius.

Tube: -2, -12 and -16: 100% seamless nylon-Type Z that easily handles a broad range of hydraulic fluids, including phosphate esters and water glycol. -3 through -8 Polyester.

Reinforcement: Synthetic fibre.

Cover: Orange urethane that resists hydraulic fluids, high temperatures, aging and weathering. Orange TH7NC is non-perforated for applications requiring electrical non-conductivity. Meets SAE 100R7 Electrical Conductivity Test. Maximum leakage shall not exceed 50 microamperes when subjected to 75 kV/ft for five minutes.

Temperature Range: -65°F to 200°F (-54°C to +93°C) continuous service for petroleum and synthetic oils. Maximum of +158°F(+70°C) for water, water/oil emulsions and water glycol.

Couplings: Super-Crimp and Gates Mega-Crimp series.

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Petroleum, water base and synthetic hydraulic fluids. Applications include: power and telephone mobile equipment (cherry pickers), lubrication lines, blowout preventer control lines, hydraulic lifts and farm and construction machinery. TH7DL hose meets or exceed performance requirements of SAE 100R7 with significantly tighter bend radius.

Tube: 100% seamless nylon- Type Z that easily handles a broad range of hydraulic fluids, including phosphate esters and water glycol.

Reinforcement: Synthetic fibre.

Cover: Black urethane that resists hydraulic fluids, high temperatures, aging and weathering. Black TH7DL is perforated for use in general hydraulic and pneumatic service.

Temperature Range: -65°F to 200°F (-54°C to +93°C) continuous service for petroleum and synthetic oils. Maximum of +158°F(+70°C) for water, water/oil emulsions and water glycol.

Couplings: Super-Crimp and Gates Mega-Crimp series.

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Petroleum, water base and synthetic hydraulic fluids. Applications include: power and telephone mobile equipment (cherry pickers), lubrication lines, blowout preventer control lines, hydraulic lifts and farm and construction machinery. Orange colour TH7NCDL meets SAE 100R7 non-conductivity requirements. TH7NCDL hose meets or exceed performance requirements of SAE 100R7 with significantly tighter bend radius.

Tube: Polyester.

Reinforcement: Braided synthetic fibre.

Cover: Orange urethane that resists hydraulic fluids, high temperatures, aging and weathering. Orange TH7NCDL is non-perforated for applications requiring electrical non-conductivity. Meets SAE 100R7 Electrical Conductivity Test. Maximum leakage shall not exceed 50 microamperes when subjected to 75 kV/ft for five minutes. (Orange is industry accepted colour for non-conductive hose).

Temperature Range: -65°F to 200°F (-54°C to +93°C) continuous service for petroleum and synthetic oils. Maximum of +158°F(+70°C) for water, water/oil emulsions and water glycol.

Couplings: Super-Crimp and Gates Mega-Crimp series.

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Petroleum and syntheic hydraulic fluids. TH18 is ideal for industrial and agricultural applications ezposed to low temperatures or cyclic and quic temperature changes. Remains highly flexible in cold wether conditions.

Standards: Meets or exceeds performance requirements of SAE100R18 with a significantly tighter bend radius

Tube: Polyester elastomer.

Reinforcement: Synthetic fibre.

Cover: Black urethane resists hydraulic fluids, high temperatures, aging and weathering. Black TH18 cover is perforated for use in general hydraulic and pneumatic service.

Temperature Range: -67°F to 212°F (-55°C to -100°C) continuous service for petroleum and synthetic oils. Maxinmum of +158°F (+70°C) for water, water/oil emulsions and water glycol.

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Petroleum and syntheic hydraulic fluids. TH18NC non-conductive hose is suitable for use in high-voltage applications. Remains highly flexible in cold wether conditions. Standards: Meets SAE100R18 performance requirements of SAE 100R18 with a significantly tighter bend radius. Meets SAE 100R18 Electrical Conductivity Test.

Tube: Polyester elastomer.

Reinforcement: Synthetic fibre.

Cover: Special orange urethane resists hydraulic fluids, high temperatures, aging and weathering. Orange TH18NC cover is non-perforated for applications requiring electrical non-conductivity.

Temperature Range: -67°F to 212°F (-55°C to -100°C) continuous service for petroleum and synthetic oils. Maximum of +158°F (+70°C) for water, water/oil emulsions and water glycol.

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Petroleum and water-based hydraulic fluids in suction lines or in low pressure return lines.

Standards: Meets or exceeds the requirements of SAE 100R4.  Meets marine ABS with use of HeatGuard high temp sleeve.  Meets Flame resistance acceptance designation MSHA 2G.

Tube: Black synthetic rubber specifically designed for resistance to high temperatures.

Temperature Range: -40°F to 212°F (-55°C to 100°C) continuous service for petroleum and synthetic oils. Maxinmum of +158°F (+70°C) for water, water/oil emulsions and water glycol.

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Low-pressure hydraulics oil return lines for general purpose water, glycol antifreeze solutions, conveying diesel fuel, gasoline or air. Meets SAE 30R2 performance requirements for both Type 1 and Type 2.

Tube: Black, synthetic rubber, oil resistant (Nitrile - Type C).

Reinforcement: One fibre braid (-3 to -10). Spiral braid (-12 to -16).

Cover: Black synthetic rubber. Oil and abrasion resistant. (Modified Nitrile - Type C).

Temperature Range: -40°F to +212°F (-40°C to +100°C). Air to +160°F (+71°C) only.

Couplings: Super-Crimp and Gates Mega-Crimp series.

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Petroleum-base hydraulic oils, water, glycol antifreeze solutions, engine lubricating oils, and air. Lock-On hose and couplings are NOT recommended for pressure surge applications or critical applications such as permanent piping in residential or commercial buildings. Do not use for gasoline of diesel fuels, unless approved by Gates H/C Product Application. Meets flame resistance acceptance designation MSHA 2G

Tube: Black, oil-resistant synthetic rubber (Modified Nitrile - Type C). Available in black-Neoprene (LOLA), blue (LOLB)< green (LOLG), red (LOLR), yellow (LOLY) and grey (LOLC) colours.

Temperature Range: -40°F to +212°F (-40°C to +100°C). For air: 160°F (+71°C) only.

Couplings: Field-Fit Lock-On series.

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Petroleum-base hydraulic oils, glycol anti-freeze compounds, water, hot lubricating oils and air. Lock-On hose and couplings are NOT recommended for vibration or pressure surge applications such as permanent piping in residential or commercial buildings.

Tube: Black, oil-resistant synthetic rubber (Nitrile - Type C).

Reinforcement: One fibre braid.

Cover: Oil and mildew resistant textile braid, impregnated with synthetic rubber.

Temperature Range: -40°F to +212°F (-40°C to +100°C).  For air: -40°F to +160°F (-40°C to +71°C).

Couplings: Field-Fit Lock-On series.

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Liquid and gaseous R134a and R12 refrigerants in automotive air conditioning and industrial systems; i.e., tractors construction trucks, mobile and stationary refrigeration units. Designed to minimize permeation of R134a refrigerant.

Tube: Black synthetic rubber (Chloroprene - Type A).

Barrier: Nylon liner.

Reinforcement: Two layers of spiral polyester.

Cover: Black synthetic rubber (EPDM).

Temperature Range: -22°F to +257°F (-30°C to +125°C).

Couplings: Gates PolarSeal series

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: On-shore /off-shore and marine Diesel fuel and gasoline applications and hot oil lines up to 202°F. Meets marine fuel specifications SAE J1527 Type A Class 1 and SAE J1942 APPLICATIONS. Exceeds performance requirements of SAE J30RZ for non-marine applications.

Tube: Nitrile - Type C.

Reinforcement: One wire braid.

Cover: Modified Nitrile - Type C Blue.

Temperature Range: -4°F to +212°F (-20°C to +100°C).

Couplings: Field-Fit C5 series.

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Petroleum-base or phosphate ester fluids; diesel fuels and filtration lines, transmission coolant lines, hot lube oil lines, power steering (CAUTION: Intended for heavy-duty commercial vehicle use only), gasoline and turbocharger oil supplies. Tilt cab cylinder and air brakes. C5D (-4 to -12) meets or exceeds DOT FMVSS 106-74 Type All, SAE J1402 Type ALL and SAE J1019 and fuel resistance of SAE J30R2.

Tube: Black, oil and heat resistant, synthetic rubber (CPE - Type J).

Reinforcement: One braid of high tensile steel wire over one braid of polyester.

Cover: Green for easy identification, oil and mildew resistant, polyester braid impregnated with synthetic rubber.

Temperature Range: -40°F to +300°F (-40°C to +149°C). Air to +250°F (+121°C) only, maximum phosphate esters to +212°F(+100°C) only.

Couplings: Field-Fit C5 series.

Recommended For: Multi-purpose hose for use on fuel lines, PVC and EEC systems, and for fuel return hose connections on diesel fuel injection systems. Approved for use with leaded and unleaded gasoline, diesel and gasoline blends of ethanol, methanol and ethers (up to the legal limit allowed by EPA).

Tube: Nitrile Rubber*

Reinforcement: Reinforced construction.

Cover: Oil resistant cover resists the effects of high heat and ozone found in engine compartments. Warning: Do not use for pressure lines on fuel injected engines or for cooling systems applications. (Use MPI Hose).

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Fuel line applications to provide flexible connections between rigid fuel distribution lines and the engine. Also for use in evaporative emission control systems and as a vent line. NOTE: Not recommended for fuel injection systems.

Tube: Nitrile - Type C.*

Reinforcement: Single ply of synthetic fibre.

Cover: Type C₂(NBR/PVC). Black, Fuel, oil , ozone and high temperature resistant.

Temperature Range: -40°F to +257°F (-40°C to +125°C)

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended for: Power steering pressure lines. Designed to meet requirements of SAE J2050 specifications.

Tube: Synthetic rubber specially compounded to provide resistance to high temperatures and power steering fluid (Hypalon - Type M).

Reinforcement: Two high-strength nylon braids that resist high temperatures and allow for expansion for system noise dampening.

Cover: Black, synthetic rubber developed specifically to resist under hood environment (Hypalon).

Temperature Range: -40°F to +300°F (-40°C to +150°C).

Couplings: Super-Crimp

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.

Recommended For: Ideal for windshield washers and vacuum-operated accessories.

Tube: Type P (EPDM). Black. Heat resistant.

Reinforcement: Non-reinforced.

Cover: Uncovered.

Temperature Range: -40°F to +257°F (-40°C to +125°C). Meets: SAE J1037, J942b

Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.
