Meets Flame Resistance Acceptance Designation MSHA 2G and ISO 11237 R17
Recommended For: High pressure hydraulic applications.
Standards: Exceeds ISO 18752 Grade B, SAE 100R17 and ISO 11237 R17 working pressure, minimum bend radius requirements and performance requirements of EN 857 1SC. M3K hose has smaller exterior dimensions and significantly tighter bend radius than other SAE 100R1 and 100R2 hose.
Tube: Black, oil resistant, synthetic rubber (Nitrile).
Reinforcement: Braided high-tensile steel wire. 1 braid (-4, -5, -6, -8) or 2 braid (-10, -12, -16).
Cover: Black, oil, abrasion and weather resistant synthetic rubber (Nitrile & PVC). Colour-coded layline. Also available with unique abrasion-resistant MegaTuff® or XtraTuff™ cover.
Temperature Range: -40°F to +212°F (-40°C to +100°C).
Refer to the Southcott Crimp Charts or Gates eCrimp database for current crimp specifications.
