Gear Pump - Group 3 Euro Cast Iron Flange

Name: Gear Pump - Group 3 Euro Cast Iron Flange
SKU: 3GPGEUR
Availability: InStock

Brand: Galtech

SKU: 3GPGEUR

UOM: EACH

Hydraulic Gear Pump 3GP Series Group 3
Body: Aluminium
Mount : Euro
Shaft: Tapered 1:8
Ports: BSPP
Rotation: Clockwise (D). Counterclockwise (S) available on request.

$0.00 inc GST

Group
Flange & Cover
cc/rev
Mount
Shaft
Ports In
Ports Out
Max Pressure Cont (bar)
Max Pressure Int (bar)
Max Pressure Peak (bar)
Max Shaft Speed (rpm)

Part Number	Group	Flange & Cover	cc/rev	Mount	Shaft	Ports In	Ports Out	Max Pressure Cont (bar)	Max Pressure Int (bar)	Max Pressure Peak (bar)	Max Shaft Speed (rpm)
3GP-G-230-D-EUR-B-N-10-0-G	3	Cast Iron	23.0	Euro	Tapered 1:8	1" BSPP	3/4" BSPP	250	265	280	3500
3GP-G-300-D-EUR-B-N-10-0-G	3	Cast Iron	30.2	Euro	Tapered 1:8	1" BSPP	3/4" BSPP	240	255	270	3300
3GP-G-340-D-EUR-B-N-10-0-G	3	Cast Iron	33.8	Euro	Tapered 1:8	1" BSPP	3/4" BSPP	240	255	270	3300
3GP-G-370-D-EUR-B-N-10-0-G	3	Cast Iron	37.5	Euro	Tapered 1:8	1" BSPP	3/4" BSPP	230	245	260	3300
3GP-G-530-D-EUR-B-N-10-0-G	3	Cast Iron	53.0	Euro	Tapered 1:8	1" BSPP	3/4" BSPP	210	225	240	3000
3GP-G-620-D-EUR-B-N-10-0-G	3	Cast Iron	62.7	Euro	Tapered 1:8	1" BSPP	3/4" BSPP	190	200	210	2500
3GP-G-700-D-EUR-B-N-10-0-G	3	Cast Iron	70.5	Euro	Tapered 1:8	1-1/4" BSPP	1" BSPP	180	190	200	2500

DIMENSIONS

GROUP 3	A		B		WEIGHT
GROUP 3	mm	inch	mm	inch	kg
3GP-G-230	63.9	2.515	131.3	5.169	7.81
3GP-G-300	66.9	2.633	137.3	5.405	8.09
3GP-G-340	68.4	2.692	140.3	5.523	8.22
3GP-G-370	69.9	2.751	143.3	5.641	8.36
3GP-G-530	76.4	3.007	156.3	6.153	8.96
3GP-G-620	80.4	3.165	164.3	6.468	9.33
3GP-G-700	86.9	3.421	170.8	6.724	9.63
