Gear Pump - Group 2 Euro Mount

Name: Gear Pump - Group 2 Euro Mount
SKU: 2SPAEUR
Availability: InStock

Brand: Galtech

SKU: 2SPAEUR

UOM: EACH

Hydraulic Gear Pump 2SP Series Group 2
Body: Aluminium
Mount : Euro
Shaft: Tapered 1:8
Ports: BSPP
Rotation: Clockwise (D). Counterclockwise (S) available on request.

$0.00 inc GST

Group
Flange & Cover
cc/rev
Mount
Shaft
Ports In
Ports Out
Max Pressure Cont (bar)
Max Pressure Int (bar)
Max Pressure Peak (bar)
Max Shaft Speed (rpm)

Part Number	Group	Flange & Cover	cc/rev	Mount	Shaft	Ports In	Ports Out	Max Pressure Cont (bar)	Max Pressure Int (bar)	Max Pressure Peak (bar)	Max Shaft Speed (rpm)
2SP-A-040-D-EUR-B-N-10-0-G	2	Aluminium	4.0	SAE-A 2-Bolt	Tapered 1:8	1/2" BSPP	1/2" BSPP	260	280	300	4000
2SP-A-060-D-EUR-B-N-10-0-G	2	Aluminium	6.0	SAE-A 2-Bolt	Tapered 1:8	1/2" BSPP	1/2" BSPP	260	280	300	4000
2SP-A-080-D-EUR-B-N-10-0-G	2	Aluminium	8.5	SAE-A 2-Bolt	Tapered 1:8	1/2" BSPP	1/2" BSPP	260	280	300	3500
2SP-A-110-D-EUR-B-N-10-0-G	2	Aluminium	11.0	SAE-A 2-Bolt	Tapered 1:8	3/4" BSPP	1/2" BSPP	260	280	300	3500
2SP-A-140-D-EUR-B-N-10-0-G	2	Aluminium	14.0	SAE-A 2-Bolt	Tapered 1:8	3/4" BSPP	1/2" BSPP	260	280	300	3500
2SP-A-160-D-EUR-B-N-10-0-G	2	Aluminium	16.5	SAE-A 2-Bolt	Tapered 1:8	3/4" BSPP	1/2" BSPP	240	250	260	3500
2SP-A-260-D-EUR-B-N-10-0-G	2	Aluminium	26.0	SAE-A 2-Bolt	Tapered 1:8	3/4" BSPP	1/2" BSPP	180	190	200	2500
2SP-A-310-D-EUR-B-N-10-0-G	2	Aluminium	31.5	SAE-A 2-Bolt	Tapered 1:8	3/4" BSPP	1/2" BSPP	140	150	160	2200

DIMENSIONS

GROUP 2	A		B		WEIGHT
GROUP 2	mm	inch	mm	inch	kg
2SP-A-040	44.4	1.748	93.0	3.661	3.40
2SP-A-060	46.0	1.811	96.3	3.791	3.55
2SP-A-080	48.1	1.894	100.5	3.957	3.70
2SP-A-110	50.2	1.976	104.6	4.118	3.80
2SP-A-140	52.7	2.075	109.6	4.315	3.90
2SP-A-160	54.8	2.157	113.8	4.480	4.05
2SP-A-260	62.7	2.469	129.6	5.102	4.50
2SP-A-310	66.9	2.636	138.0	5.437	4.71
